DIMENSIONS & WEIGHTS			Double Cab	Double Cab 4WD
Overall length (with rear step bumper)		(mm)	5,135
Overall width		(mm)	1,695
Overall height		(mm)	1,625	1,753
Wheelbase		(mm)	2,985	3,000
Tread	Front	(mm)	1,410	1,420
	Rear	(mm)	1,410	1,420
Min. ground clearance		(mm)	179	211
Kerb weight		(kg)	1,531	1,699
Gross vehicle weight		(kg)	2,618	2,786
Seating capacity			5	5
Min. turning circle (kerb-to-kerb)		(m)	12.0	12.6
ENGINE
Type			In-line, 4-cyclinder, SOHC
Displacement		(cc)	2,892
Compression ratio			22.1:1
Max. output (DIN Net)			69 kW / 4,000 rpm
Max. torque (DIN Net)			200 nm / 2,500 rpm
Fuel injection type			Mechanical
Fuel tank capacity		(litre)	63	70
STEERING
Gear type			Ball and nut
Power steering type			Engine speed sensing
DRIVE TRAIN
Transmission type			5-speed manual
Gear	1st		4.250
	2nd		2.356
	3rd		1.428
	4th		1.000
	5th		0.827
	Reverse		3.656
Final gear ratio			4.100	4.444
SUSPENSION
Type	Front		Independent (double wishbone)
	Rear		Rigid (leaf spring)
BRAKES
Type	Front		Ventilated disc
	Rear		Drum (leading / trailing with auto adjuster)
